Sturdy servo electric gripper with substantial gripping power and stroke range RM-GB-17-120-2-1-H

Servo gripper (RM-GB-17-120-2-1-H) is a robust servo gripper designed for exceptional performance, offering immense gripping force and precise control capabilities. The key features of this gripper include:

- Superior rigidity, ability to handle high loads, exceptional precision, and utmost reliability, making it adaptable to various complex working environments.
- A wide range of strokes and comprehensive specifications, catering to different application requirements.
- Compatibility with diverse collaborative robots and industrial robots, enabling it to seamlessly complete tasks such as assembly, transportation, and palletizing across a wide range of item weights.

The Servo gripper (RM-GB-17-120-2-1-H) boasts a gripping stroke of 120mm, a lead of 2, and supports side wire outlet as well as vertical wire outlet modes. It has an impressive maximum effective load capacity of up to 7 kg, which is 2-3 times its own weight. Additionally, it offers a market-leading gripping force of 500N, ensuring optimal performance in comparison to similar products. Whether dealing with heavy-duty or delicate micro items, this gripper excels. With a reliable service life of up to 10 million cycles, it can withstand extreme loads while maintaining unmatched stability.

Specifications

Output Cable: Side Wiring

Outgoing Line Method: Horizontal Wiring

Stroke (mm): 120

Max.Gripping Force (N): 700

Max.speed (mm/s): 100

Repeat Positioning Accuracy (mm): ±0.02

Backlash (mm): < 0.1 ( Single-Side)

Permissible Load Torque (N.m): MR:60, MP:30, MY:40

Compatible Controllers: RM-C-40, RM-CEP-40, RM-CEU, RM-CEM

Rated Voltage: DC24±10%

Rated Current (A): 4

Weight (kg): 3.6

Usage Environment: 0~40℃,< 85%RH ( Without Condensation)

Protection Class IP: IP40
